Top Features
- 3-phase bridge MOSFET driver
- Bootstrap gate drive for N-channel MOSFET bridge
- Cross-conduction protection with adjustable dead time
- Charge pump for low supply voltage operation
- Programmable gate drive voltage and strength
- 4.5 to 50 V supply voltage operating range
- Integrated logic supply
- Three programmable current sense amplifiers
- SPI-compatible serial interface
- Bridge control by direct logic inputs or serial interface
- Extensive programmable diagnostics
- Diagnostic verification
- Safety assist features
- Automotive AEC-Q100 qualified
