Product Details
Product Details
Top Features
- Supply voltage 6 to 48 V
- True average output current control
- 3.0 A maximum output over operating temperature range
- Cycle-by-cycle current limit
- Integrated MOSFET switch
- Dimming via direct logic input or power supply voltage
- Internal control loop compensation
- Undervoltage lockout (UVLO) and thermal shutdown protection
- Low power shutdown (1 μA typical)
- Robust protection against:
- Adjacent pin-to-pin short
- Pin-to-GND short
- Component open/short faults
