Top Features
-
AEC Q-100 qualified
-
Total LED drive current up to 400 mA (LP, LJ, and LY packages) or 300 mA (LJ)
-
Current shared equally up to 100 mA by up to 4 strings (LP and LY)
-
6 to 50 V supply
-
Low dropout voltage
-
LED output short-to-ground and thermal protection
-
Disable on open LED detection option
-
Enable input for PWM control
-
Current slew rate limit during PWM
-
Current set by reference resistor
- Automotive temperature range (K, –40°C to 150°C)
