Low Noise, High Precision, Factory-Programmed Linear Hall Effect Sensor IC With Advanced Temperature Compensation and High Bandwidth (120 kHz) Analog Output

A1366

Factory programmed sensitivity and quiescent output voltage with high resolution
Proprietary segmented linear interpolated temperature compensation (TC) technology provides a typical accuracy of 1% across the full operating temperature range
Extremely low noise and high resolution achieved via proprietary Hall element and low noise amplifier circuits
120 kHz nominal bandwidth achieved via proprietary packaging and chopper stabilization techniques
Patented circuits suppress IC output spiking during fast current step inputs
Open circuit detection on ground pin (broken wire)
Undervoltage lockout for V_CC below specification
Ratiometric sensitivity and quiescent voltage output
Precise recoverability after temperature cycling
Wide ambient temperature range: –40°C to 150°C
Immune to mechanical stress
Extremely thin package: 1 mm case thickness
AEC Q-100 automotive qualified
