Magnetic Position Sensors
Stray Field Immune, High-Speed, Hall-Effect Angle Sensor IC for Electrified Vehicles in Single and Dual Die Package
A33023
The A33023 and the A33023-DD are stray field immune, 360° angle sensor ICs that provide high-resolution angular position information based on magnetic sensing technology. They include integrated linearization features which allow the device to correct for misalignment between the IC and the target magnet.
Product Details
Product Details
Top Features
- Stray-field immune
- Designed to meet ASIL D requirements when used in conjunction with appropriate system-level control
- High accuracy and resolution
- Low latency
- Wide operating voltage (3.7 V to 18 V)
