Top Features
- Three-wire back-biased speed sensor optimized for transmission speed-sensing applications
- Integrated in-package EMC protection circuit allows compliance to most Automotive EMC environments without external circuitry
- Small-signal lockout for immunity to vibration
- Tight timing accuracy over full operating temperature range
- True zero-speed operation
- Air gap independent switchpoints
- Large operating air gaps achieved through use of gain and offset adjust circuitry
- Wide operating voltage range with undervoltage lockout (UVLO)
- Digital output representing target profile
- Single-chip sensing IC for high reliability
- High-speed startup
