Low Power 3D Magnetic Position Sensor with SPI & I²C Interfaces and Angle Output
A31301
The A31301 is a low power 3D magnetic position sensor capable of reading the X, Y, and Z axis magnetic fields and calculating a position from them.
Product Details
Product Details
Top Features
- Magnetometer with XYZ output
- 15-bit onboard angle output from any 2 axes
- <2° typ angle error for good accuracy in XY and XZ/YZ configurations
- Interrupt/Switch pin for wakeup and triggering
- SPI or I2C output for easy interfacing to most microcontrollers
