40 V, 2.5 A, Synchronous Buck Regulator with Low EMI and 6 µA Quiescent Current

• Wide input voltage range: 3.5V to 40V
• AEC-Q100 Grade 0 qualified
• High efficiency: 92%, 12 to 5V at 1A
• Low EMI: spread spectrum dithering
• Wide switching frequency range: 250kHz to 2.5MHz
• Up to 2.5A continuous output current

Typical Applications:

• Infotainment
• Battery-Powered Systems
• Industrial Systems
• Container Tracking
• Handheld Instruments
• Audio Systems
• ADAS
  • Instrument clusters
  • Power Steering
  • Radar
