Allegro 电流传感器

400kHz, High-Precision Linear Sensor IC with Vref and Overcurrent Fault

ACS37600

Product Details

Top Features

  • User programmable bandwidth (100 to 400 kHz)
  • Very fast response time (<1.25 μs typ.)
  • User programmable, bidirectional reference pin (VREF)
  • User-programmable overcurrent fault (OCF)
  • User-programmable sensitivity over temperature for ferromagnetic core drift compensation
