Allegro 电流传感器
1 MHz Bandwidth Contactless Current Sensor Optimized for High dV/dt Applications
CT455
Product Details
Product Details
Top Features
- Optimized for high dV/dt applications
- Integrated Contactless Current/Field Sensor
- Linear Analog Output Voltage
- 1 MHz Bandwidth
- Response Time < 300 ns
- Supply Voltage: 3.3 V to 5.0 V
- Low Noise Performance
- AEC-Q100 Grade 1
- Package Options:
- 8-lead SOIC
- 8-lead TSSOP
Part Number Specifications and Availability
