Discover the next generation of magnetic sensing
高效功率转换
精确测量整个动态范围，提供更清晰的信号。
采用宽带隙晶体管
GAN 和 SiC 等宽带隙晶体管需要高带宽的电流传感器，XtremeSense TMR 在不牺牲精度和分辨率的情况下实现了这一点。
减少能源足迹
提供所有磁传感产品类别中最低的功耗。
Product Details
Product Details
Top Features
- Optimized for high dV/dt applications
- Integrated Contactless Current/Field Sensor
- Linear Analog Output Voltage
- Differential measurements
- 1 MHz Bandwidth
- Response Time < 300 ns
- Very low noise: 0.92mVrms (@100kHz)
- Supply Voltage: 3.3 V to 5.0 V
- AEC-Q100 Grade 1
- Package Options:
- 8-lead TSSOP
Part Number Specifications and Availability
Allegro's XtremeSense™ TMR technology
Superior magnetic sensitivity, low power consumption, and compact size compared to other technologies, driving innovation in applications like renewable energy, electric vehicles, and consumer electronics.
