Allegro's XtremeSense™ TMR technology
Superior magnetic sensitivity, low power consumption, and compact size compared to other technologies, driving innovation in applications like renewable energy, electric vehicles, and consumer electronics.
Product Details
Product Details
Top Features
- 总输出误差：<±0.5%（典型）
- 分辨率：5 mA
- 采样频率：200 kHz
- 电源电流：1.2 mA
- FLAG 引脚指示全电流范围的 90% 和 10%
- 电源电压：2.7 V 至 5.5 V
- 2kV 隔离
- 交流或直流电流范围：
- +5.0 ADC / ±5.0 APK
- +10.0 ADC / ±10.0 APK
- +15.0 ADC / ±15.0 APK
- 封装：6 引线 DFN，3.00 x 3.00 x 0.95 mm
Part Number Specifications and Availability
Design Tools
Technical Documentation
Application Note
Glossary of Isolation-Related Terms for Integrated Current Sensors
Application Note
Calibration Guide for CT110, CT220 and CT450
Application Note
What is XtremeSense TMR
Application Note
CT110: Replacement for Shunt Resistor-Plus-Isolated Amplifier System
Application Note
Low-Current Sensing Applications
Brochure
感测技术的未来: XtremeSense™ TMR 技术
Brochure
通过可持续性实现舒适性
Guide
EVB111-5A Evaluation Board User Manual
Guide
