Top Features
- Interface pressure sensor qualified with AEC-Q100 Grade 0
- Analog, PWM and SENT output.
- On-chip Poly(4,4) compensation for improved accuracy over temperature, compensating both IC and bridge
- Manchester interface for programming through single OUT pin
- Suite of diagnostics to allow for safety-critical systems fault detection
- QFN package with wWettable flanks enabling visual inspection of solder joints
Part Number Specifications and Availability
Design Support Tools
Technical Documentation
Application Note
Calibration of A17700 Pressure Sensor Interface
Application Note
Guide and Usage of Resistive Bridges for Pressure Measurement with A17700
Application Note
Using SENT Communication Output Protocol with A17700 Pressure Interface Sensor
Brochure
Brochure: A17700 Accuracy Under Pressure
Brochure
电动汽车热管理系统
